220V Diesel Welding Generator 6500EAW Genset Diesel Welder Generator

Product Details

Place of Origin: China

Brand Name: GET

Certification: ISO CE

Document: Product Brochure PDF

Payment & Shipping Terms

Price: Negotiable

Delivery Time: 15-20 workdays

Payment Terms: LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    220v diesel welding generator, diesel welding generator 6500eaw, 6500eaw genset diesel welder generator


Rated Frequency:	50hz 60hz	Rated Power (kw):	2 5
Rated Voltage (V):	220V Or As Request	Rated Currency (A):	8.7 9.5A
Rated Rotation Speed (r/min):	3000 3600	Phase No.:	Single Phase
Power Factor:	1	No Load Welding Voltage:	65-70V
Insulation Grade:	F	Pole Number:	2
Engine Mode:	GET186FA GET192F	Displacement(ml):	418 456
Engine Type:	Single Cylinder, Vertical, Four Stroke, Direct Injection, Air-cooled	Bore X Stroke (mm):	1-86x72/ 1-92x75
Compression Ratio:	19:01	Rated Power:	5.7 6.3/ 7.2 8.2
Lubrication System:	Pressure Splashed	Lube Oil Brand:	CD Grade Or SAE10W-30, 15W-40
Lube Capacity (L):	1.65	Fuel Type:	0#(summer)-10#(winter)-35#(chillness) Diesel
Fuel Consumption (g/kw*h):	≤280	Fuel Tank Capacity (L):	13.5
Continuous Running Time:	8h	Rated Welding Current:	180A 220A
Welding Voltage:	25-30V	Welding Load Continous Ratio:	60%
Welding Current Adjustment Range:	50-180A/ 50-200A	Electrode Diameter:	1.6-3.2mm 1.6-5.0mm
Excitation Mode:	Seperate-excitation+AVR Voltage Regulation AVR	Rectifying Mode:	Diode
Connection Mode:	Drive Bearing, Rigid Connection	Overall Dimension:	720x492x655mm
Structure Type:	Open Type	Dry Weight:	112kg 116kg

Rated Frequency:	50hz 60hz
Rated Power (kw):	2 5
Rated Voltage (V):	220V Or As Request
Rated Currency (A):	8.7 9.5A
Rated Rotation Speed (r/min):	3000 3600
Phase No.:	Single Phase
Power Factor:	1
No Load Welding Voltage:	65-70V
Insulation Grade:	F
Pole Number:	2
Engine Mode:	GET186FA GET192F
Displacement(ml):	418 456
Engine Type:	Single Cylinder, Vertical, Four Stroke, Direct Injection, Air-cooled
Bore X Stroke (mm):	1-86x72/ 1-92x75
Compression Ratio:	19:01
Rated Power:	5.7 6.3/ 7.2 8.2
Lubrication System:	Pressure Splashed
Lube Oil Brand:	CD Grade Or SAE10W-30, 15W-40
Lube Capacity (L):	1.65
Fuel Type:	0#(summer)-10#(winter)-35#(chillness) Diesel
Fuel Consumption (g/kw*h):	≤280
Fuel Tank Capacity (L):	13.5
Continuous Running Time:	8h
Rated Welding Current:	180A 220A
Welding Voltage:	25-30V
Welding Load Continous Ratio:	60%
Welding Current Adjustment Range:	50-180A/ 50-200A
Electrode Diameter:	1.6-3.2mm 1.6-5.0mm
Excitation Mode:	Seperate-excitation+AVR Voltage Regulation AVR
Rectifying Mode:	Diode
Connection Mode:	Drive Bearing, Rigid Connection
Overall Dimension:	720x492x655mm
Structure Type:	Open Type
Dry Weight:	112kg 116kg

Description

220V Diesel Welding Generator 6500EAW Genset Diesel Welder Generator

Open Type Diesel Powered Welder GET6500EAW Diesel Welding Generator

The GET6500EAW Diesel Welding Generator is a specific model of diesel welding generator. While I don't have information on this specific model as my knowledge cutoff is in September 2021, I can provide you with a general overview of the features commonly found in diesel welding generators. Please note that the features may vary depending on the manufacturer and model. Here are some typical features you might find in a diesel welding generator:

Rated Power (kw):	2 5
Rated Currency (A):	8.7 9.5A
Phase No.:	Single Phase
No Load Welding Voltage:	65-70V
Pole Number:	2
Displacement(ml):	418 456
Bore X Stroke (mm):	1-86x72/ 1-92x75
Rated Power:	5.7 6.3/ 7.2 8.2
Lube Oil Brand:	CD Grade Or SAE10W-30, 15W-40
Fuel Type:	0#(summer)-10#(winter)-35#(chillness) Diesel
Fuel Tank Capacity (L):	13.5
Rated Welding Current:	180A 220A
Welding Load Continous Ratio:	60%
Electrode Diameter:	1.6-3.2mm 1.6-5.0mm
Rectifying Mode:	Diode
Overall Dimension:	720x492x655mm
Dry Weight:	112kg 116kg
Rated Frequency:	50hz 60hz
Rated Voltage (V):	220V Or As Request
Rated Rotation Speed (r/min):	3000 3600
Power Factor:	1
Insulation Grade:	F
Engine Mode:	GET186FA GET192F
Engine Type:	Single Cylinder, Vertical, Four Stroke, Direct Injection, Air-cooled
Compression Ratio:	19:01
Lubrication System:	Pressure Splashed
Lube Capacity (L):	1.65
Fuel Consumption (g/kw*h):	≤280
Continuous Running Time:	8h
Welding Voltage:	25-30V
Welding Current Adjustment Range:	50-180A/ 50-200A
Excitation Mode:	Seperate-excitation+AVR Voltage Regulation AVR
Connection Mode:	Drive Bearing, Rigid Connection
Structure Type:	Open Type

Fuel Efficiency: Diesel welding generators are generally known for their fuel efficiency, allowing for longer operation times without frequent refueling.
Safety Features: The generator should include safety features such as overload protection, low oil shutdown, and circuit breakers to protect both the generator and connected equipment.
Portability: Depending on the model, the generator may have built-in handles, wheels, or a compact design to enhance portability and ease of transportation.
Noise Reduction: Some diesel welding generators incorporate noise-reducing features such as soundproof enclosures or mufflers to minimize noise levels during operation.
Multiple Power Outlets: The generator may provide various power outlets, such as AC sockets or industrial plugs, to accommodate different electrical devices and tools.
